Product Overview
XTKB-900A/B Intelligent Control Device (or Smart Controller) is a computer-based control unit embedded within electronic equipment or systems. It acts as the “brain” of a system, automatically identifying, processing, and responding to information to achieve precise automated control over a target device or environment.
Functional Description
It features dynamic simulation display graphics, temperature and humidity control inside the cabinet, high-voltage live display and locking function, voice anti-misoperation prompts, on/off switch indication, energy storage indication, remote/local operation, on/off switch operation, Chinese LCD display, field programmability, digital lighting switch, and automatic human body sensing. The S-485 communication interface is also included. This product is designed as an integrated layout to complement the switch cabinet, greatly simplifying the structural design of the switch cabinet and beautifying the panel layout.
This product boasts an exquisite appearance and high cost-effectiveness, effectively elevating the grade of switchgear.
Main Functions & Technical Parameters
| Item | Parameter |
|---|---|
| High-brightness LED Display | — |
| Selectable Temperature & Humidity Control Setpoints | — |
| Operating Voltage | AC/DC 165~265V |
| Insulation Performance | ≥ 1000MΩ |
| Power Consumption of Voltage Circuit | ≤ 12VA |
| Anti-Electromagnetic Interference | Complies with IEC255-22 |
| Dynamic Blink Frequency | 2 times/sec |
| Association Between Digital Input Terminals and LED Digital Display | Dynamic Configuration |
| Communication Mode | RS485, ModBus Protocol |
Overall Dimensions: 185mm (H) × 238mm (W)
Cutout Dimensions: 165mm (H) × 220mm (W)
